ITEMS
|
FI8601W
|
|
Image Sensor
|
Image Sensor
|
SONY Color CCD Sensor
|
|
Lens
|
f:6mm,8mm,12mm optional, F:1.2
|
|
Mini. Illumination
|
0.1Lux
|
|
Lens
|
Lens Type
|
Glass Lens
|
|
Visual Angle
|
48°(6mm lens), 35°(8mm lens), 25°(12mm lens)
|
|
Video
|
Video Formats
|
Supports NTSC or PAL Formats
|
|
Image Compression
|
H.264
|
|
Image Frame Rate
|
25fps(PAL Formats), 30fps(NTSC Formats),Down adjustable
|
|
Image Resolution
|
D1(720*576),CIF(352*288),QCIF(176*144)
|
|
View
|
H.264 dual streaming
|
|
White balance
|
Automatic white balance
|
|
Backlight compensation
|
Automatic backlight compensation
|
|
SNR
|
>48DB (AGC OFF)
|
|
Video Parameters
|
Brightness, Contrast
|
|
Night Visibility
|
Φ5mm 36 IR LEDs, Night visibility up to 30 meters
|
|
Audio
|
Audio Compression
|
G.711/G.726
|
|
Sample Rate
|
128Kbps~2.048Mbps
|
|
Input/Output
|
Linear Input/Output, support two-way audio
|
|
PC Requirements
|
CPU
|
2.0GHZ or above (suggested 3.0GHZ)
|
|
Memory Size
|
256MB or above (suggested 1.0GHZ)
|
|
Display Card
|
64M or above
|
|
Supported OS
|
Microsoft Windows 2000/XP,Vista,Windows7,Mac OS,Linux
|
|
Browser
|
IE,Firefox,Safari,Goolge Chrome,other standard browsers
|
|
Smart phone Support
|
Support phone OS
|
iOS,Symbian,Windows Mobile,Blackberry,Android
|
|
Power
|
Power Supply
|
DC 12V/2.0A (EU,US,AU,UK plug)
|
|
Power Consumption
|
<8 Watts
|
|
Network
|
Ethernet
|
One 10/100Mbps RJ-45
|
|
Supported Protocol
|
HTTP,FTP,TCP/IP,UDP/IP,SMTP,DHCP,DDNS,UPNP
|
|
Wireless
|
Wireless Standard
|
IEEE 802.11b/g/n
|
|
Data Rate
|
802.11b:11Mbps(Max.) 802.11g:54Mbps(Max.)
802.11n: 150Mbps(Max.)
|
|
Wireless Security
|
WEP & WPA & WPA2 Encryption
|
|
Physical
|
Dimension
|
200mm(L)x90mm(W)x87mm(H)
|
|
Gross Weight
|
1411g(Color Box Size:295*120*203mm)
|
|
Net Weight
|
909g
|
|
Environment
|
Operate Temper.
|
-20° ~ 55°C (- 4°F ~ 131°F)
|
|
Operating Humidity
|
20% ~ 85% non-condensing
|
|
Storage Temper.
|
-20°C ~ 60° (- 4°F ~ 140°F)
|
|
Storage Humidity
|
0% ~ 90% non-condensing
|
|
Certification
|
CE,FCC
|
|
Warranty
|
Limited 2-year warranty
|
