ITEMS
|
FI8905W
|
|
Image Sensor
|
Image Sensor
|
High Definition Color CMOS Sensor
|
|
Display Resolution
|
640 x 480 Pixels(300k Pixels)
|
|
Lens
|
f:6mm,8mm,12mm optional
|
|
Mini. Illumination
|
0.5Lux
|
|
Lens
|
Lens Type
|
Glass Lens
|
|
Visual Angle
|
30°(6mm lens), 25°(8mm lens), 15°(12mm lens)
|
|
Video
|
Image Compression
|
MJPEG
|
|
Image Frame Rate
|
15fps(VGA),30fps(QVGA)
|
|
Resolution
|
640 x 480(VGA), 320 x 240(QVGA)
|
|
Flip Mirror Images
|
Vertical / Horizontal
|
|
Light Frequency
|
50Hz, 60Hz or Outdoor
|
|
Video Parameters
|
Brightness, Contrast
|
|
Night Visibility
|
60 IR LEDs, Night visibility up to 30 meters
|
|
PC Requirements
|
CPU
|
2.0GHZ or above (suggested 3.0GHZ)
|
|
Memory Size
|
256MB or above (suggested 1.0GHZ)
|
|
Display Card
|
64M or above
|
|
Supported OS
|
Microsoft Windows 2000/XP,Vista,Windows7,Mac OS,Linux
|
|
Browser
|
IE6/IE7/IE8/IE9,Firefox,Safari,Goolge Chrome,
|
|
other standard browsers
|
|
Smart phone Support
|
Support phone
|
iphone,Blackberry,Android,Symbian,Windows
|
|
Mobile,smart phone support JAVA,
|
|
Power
|
Power Supply
|
DC 5V/2.0A (EU,US,AU,UK plug)
|
|
Power Consumption
|
7 Watts (Max.)
|
|
Network
|
Ethernet
|
One 10/100Mbps RJ-45
|
|
Supported Protocol
|
HTTP,FTP,TCP/IP,UDP,SMTP,DHCP,PPPoE,DDNS,UPnP,GPRS
|
|
Wireless
|
Wireless Standard
|
IEEE 802.11b/g/n
|
|
Data Rate
|
802.11b:11Mbps(Max.) 802.11g:54Mbps(Max.) 802.11n:150Mbps(Max.)
|
|
Wireless Security
|
WEP & WPA & WPA2 Encryption
|
|
Physical
|
Dimension
|
180(L) x98(W) x103mm(H)
|
|
Gross Weight
|
1150g(Color Box Size:250X120X200mm)
|
|
Net Weight
|
953g
|
|
Environment
|
Operate Temper.
|
-20° ~ 55°C (-4°F ~ 131°F)
|
|
Operating Humidity
|
20% ~ 85% non-condensing
|
|
Storage Temper.
|
-20°C ~ 60°C (- 4°F ~ 140°F)
|
|
Storage Humidity
|
0% ~ 90% non-condensing
|
|
Certification
|
CE,FCC
|
|
Warranty
|
Limited 2-year warranty
|
